Red COB Strip 24V 10W 512leds/m 620nm 630nm 180° red led strip
MR-CM0000240804C-Red
The biggest feature of COB LED strips is 'light, but no visible light source' — they emit a continuous, uniform light strip without the annoying 'graininess' or 'speckles' found in traditional LED strips. This is mainly due to their unique COB (Chip-on-Board) packaging technology: a large number of LED chips are densely arranged and directly encapsulated on a flexible circuit board, forming a continuous linear light source.
* High-density COB chips, soft light and brighter light
* The LED chip is directly mounted on the FPC
* The high thermal conductivity flexible PCB design enables free bending and easy installation
* IP Rating lP20
* Ambient Temperature: -4°F to 104°F (-20°C to 40°C)
* Lamp Life : 50,000 Hours
* High-density COB chips, soft light and brighter light
* The LED chip is directly mounted on the FPC
* The high thermal conductivity flexible PCB design enables free bending and easy installation
* IP Rating lP20
* Ambient Temperature: -4°F to 104°F (-20°C to 40°C)
* Lamp Life : 50,000 Hours
Quantity
Product Certification
Product Parameters
| Product model | Input Voltage | Power | LED Type | PCB width | LED Qty | Cuttable Size | CCT | Lumen/M | Beam Angle | IP Rating | Length per roll |
| MR-CM0000240804C-Red | 24V | 10W/M | COB | 8mm | 512LEDs/M | 62.5mm | Red | 620-630nm | 180° | IP20 | 5M/Roll |
ProductApplication
Due to their uniform light emission, no visible light spots, high color rendering index, and flexible bendability, COB LED strips have a very wide range of applications, mainly covering areas such as residential, commercial, automotive, and creative display.
